Спецификация:

• LTE/3G Air Interface
• Standard compliant: 3GPP Release 8 Category 3
• Supported frequency:
• LTE FDD 800/2600MHz (Band 7/20)
• HSPA+ 900/2100 MHz
• EGPRS 900/1800 MHz
• Tx Power/Rx Sensitivity:
• Band7 maximum output power: 23 dBm (typical 23, +2/-1.5) m; Rx Level: -92 dBm (typical)
• Band20 maximum output power: 23 dBm (typical 23, +2/-1.5); Rx Level: -96 dBm (typical)
• Data speed:
• 100 Mbps DL and 50 Mbps UL @20 MHz Bandwidth
• HSPA+: 21 Mbps DL/5.76 Mbps UL
• HSPA: 14.4 Mbps DL/5.76 Mbps UL
• WCDMA: 384 Kbps UL/DL
• GPRS/EDGE: 296 Kbps DL/236.8 Kbps UL
• Optional HW capable for LTE B3 and B8 and DC-HSPA+ by regions
• WLAN Function
• IEEE 802.11 compliance (1X1 802.11n)
• Clients: Configurable client number up to 10 stations
• Multiple SSID: 2 simultaneous SSID with separate security mode
• 802.11 b/g/n 2.4 GHz, 20 MHz bandwidth
• Routing
• Dynamic Host Configuration Protocol (DHCP)
• RFC2131/2132/2939
• Dynamic IP address assignment on WLAN side
• DNS
• RFC1034/1035/2181/2782
• DNS proxy
• ICMP
• IPv4
• Network Address Translation (NAT)
• Max 2048 sessions
• Port forwarding: 10 entries in web UI
• Security
• Authentication: PAP/CHAP
• Firewall
• Static Packet Inspection (SPI)
• IP/Port filtering
• Management
• Web GUI:
• FOTA: firmware upgrade
• System status and configuration
• System date and time
• Hardware Specifications
• Reset button
• Power/WPS switch
• USB 2.0 port
• LED indicator:
• Green: working status
• Red: error warning
• Orange: processing
• Display: 1 inch single color OLED
• Antenna: 1Tx2R MIMO antenna for LTE and 1Tx1R antenna for Wi-Fi
• Battery: Li-Ion battery, 3.7 V/1700 mAh
• Power consumption:
• 3.7 watt max. (powered with battery)
• 5 watt max. (connected with adapter)
• Power supply: 5 V DC,1 A (connected with adapter)
• Physical Specifications
• Item dimensions (WxDxH): 89 x 88 x 17 mm (3.5” x 3.46” x 0.67”)
• Item weight: 124 g (0.27 lb.)
• Packing dimensions (WxDxH): 131 x 118 x 56 mm (5.16” x 4.64” x 2.2”)
• Packing weight: 310 g (0.68 lb.)
• Environmental Specifications
• Operating Environment:
• Temperature: -5°C to 45°C (23°F to 113°F)
• Humidity: 0% to 90% (Non-condensing)
• Storage Environment
• Temperature: -20°C to 70°C (-4°F to 158°F)
• Humidity: 0% to 95% (Non-condensing)
• Certification
• CE certification: RF/EMC/SAR/Safety
• GCF compliance: GSM/WCDMA/LTE/SIM-UICC
• WAH7130 can also support LTE frequency 1800/900MHz (Band 3/8) optionally and reserve in hardware design.
